AeroTech N4000W-PS RMS-98/20480 Reload Kit (1 Pack) - 14400P

  • Sale
  • Regular price $1,799.99
Shipping calculated at checkout.


AVAILABLE FOR PRE-ORDER FROM AUTHORIZED AEROTECH DEALERS!



The AeroTech Reloadable Motor System RMS is an aluminum cased reusable motor in kit form that is assembled by the user. You will need AeroTech RMS-98/20480 motor hardware to build and complete the motor for many reliable flights. Motor hardware is available separately in a complete set, and also as individual parts. This motor requires installing a forward seal disc Stainless Steel (98FSDSS) during assembly. Important: High Power RMS reload kits are not compatible with Mid Power RMS products.

The N4400W-PS is a Plugged/Smoke motor reload. Plugged reload kits do not utilize a motor-actuated delay or ejection charge. Plugged motors must be used in conjunction with a timer, altimeter or radio-activated recovery system.

This RMS motor reload utilizes RCS' exclusive White Lightning™ aerospace grade composite propellant formulation.

The AeroTech motor reload kit comes with 1 rocket motor reload. Reload kits include all internal motor components and FirstFire™ Initiators. Requires HAZMAT shipping via UPS or FEDEX. The sale of this high power motor to persons under 18 years of age is currently prohibited by federal law. This is a High-Power motor requiring Level 3 High-Power certification through NAR or Tripoli to purchase. Orders containing this item will not be shipped until proof of age (such as a copy of a driver’s license) and proof of Level 3 certification is received. Also, this motor requires U.S. State Department Licensing (SDL) for export (international shipments). Not available for sale in California.

Certified by the Tripoli Rocketry Association (TRA), the National Association of Rocketry (NAR) and the Canadian Association of Rocketry (CAR).

  • Specifications:

    Motor Diameter: 3.875 inches (98mm)

    Casing Length: 41.18 inches (1046mm)

    Hardware Required: RMS-98/20480

    Total Impulse: 18540 N-sec

    Peak Thrust: 5320 N-sec

    Thrust Duration: 4.6 seconds

    Delay Time: Plugged with Smoke

    Propellant Weight: 9800 grams

    Motor Weight: 16252 grams

    Maximum Liftoff Weight: Due to the variables involved, AeroTech/Quest currently does not list or post recommended maximum lift-off weights for their mid-power and high-power rocket motors. Instead, we recommend utilizing either the RockSim software available at www.apogeerockets.com or OpenRocket Simulator available at www.openrocket.info.
